Rotatable, round LED surface mount luminaire LED PIPE, Ø1.4cm, 31cm, 7.5W 4000K

Rotatable, round LED surface-mounted luminaire LED PIPE

The rotatable, round LED surface-mounted luminaire LED PIPE is an elegant lighting solution for indoor spaces. With a diameter of 1.4 cm and a length of 31 cm, it fits perfectly into furniture or on walls. The luminaire features an aluminum surface in aluminum color and opal plastic for pleasant light distribution.

Technical Details

This LED surface-mounted luminaire operates at a voltage of 24V and a constant current of 315mA. The power consumption is 7.5W, with a light output of 61lm/W and a luminous flux of 475lm. The color temperature is 4000K and the color rendering index is between 90-100Ra.

Installation and Application

The LED PIPE can be mounted as a recessed or surface-mounted luminaire. With the LED-24 plug-in system, the connection is simple and uncomplicated. The luminaire has a wide range of applications, from residential spaces to offices and commercial areas. It is suitable for use in furniture and on walls.

Additional Information

The LED surface-mounted luminaire has an extremely wide beam of light with a beam angle of over 80°. It is suitable for light band configurations and has through-wiring. The operating device is voltage-controlled and the average lamp lifespan is 50,000 hours. The luminaire complies with protection class 3 and has energy efficiency class G.

Accessories and Dimming Function

The LED PIPE comes with an LED operating device, but without a light distributor. It can be dimmed with the appropriate accessories. The plug type is LED-24, and the luminaire has an IP protection of 20. Replacement of the light source is not provided as it is an LED with built-in light sources.
