LED panel STAR 600 CCT Switch, switchable, multipower, 22,5 - 30W 4500lm 3000/4000K 110° CRI >80

High-Quality LED Recessed Panel STAR 600 for Efficient Lighting

The LED recessed panel STAR 600 from Radium impresses with its modern technology and high-quality workmanship. With dimensions of 59.5 x 59.5 cm, it fits perfectly into standardized grid ceilings. The panel features an elegant white aluminum frame with a powder-coated steel carrier plate and an opal polystyrene diffuser that ensures even light distribution. With a slim construction height of only 3.3 cm, the panel integrates discreetly into any ceiling structure.

Flexible Light Colors and Power Options Thanks to CCT Switch and Power Select

The STAR 600 LED panel offers an individually adjustable color temperature ranging from warm white (3000K) to neutral white (4000K). This stepless selection is easily made via an external switch on the intermediate module. Additionally, the power can be adjusted from 22.5 to 30 watts via a DIP switch on the external LED driver. This allows the luminous flux to vary between 3150 and 4500 lumens depending on the setting, enabling optimal adaptation to different requirements.

Energy Efficiency and Long Service Life for Sustainable Lighting

With a luminous efficacy of 150 lm/W, the LED panel is extremely energy-efficient and consumes only 30 kWh per 1000 operating hours. The average lamp lifetime of 70,000 hours significantly reduces maintenance effort and replacement costs. Protection class 2 and IP40 protection rating guarantee safe use, while the mains frequency of 50/60 Hz and operating voltage of 220-240 V ensure stable power supply.

Good Color Rendering and Glare-Free Light for Pleasant Work Environments

The panel delivers high-quality light with a color rendering index of over 80 Ra, making colors appear natural and clear. The low glare value (UGR < 22) protects the eyes and provides comfortable illumination, ideal for offices, corridors, or other work areas. The color consistency with a MacAdam value of under 3 guarantees an almost identical light color across multiple luminaires, which is particularly important for larger lighting installations.

Easy Installation and Versatile Applications

The LED recessed panel STAR 600 is equipped with spring terminal connectors that enable tool-free mounting. The through-wiring at the external operating device facilitates installation and ensures safe low-voltage operation. The scope of delivery includes both the light color switch module and the LED driver as well as a power switch. The EL certification also allows integration into emergency lighting systems, highlighting the product's versatility.
