    corner connector MINI AMP FLEX CRI919/940 12V tunable white, with lighting

    ISOLED

    F
    Product data sheet

    2,87 EUR

    excl. Shipping costs (from 99,00 EUR free shipping) / incl. 19 % VAT
    Recommended retail price: 4,88 EUR

    You save 41,2 %

    Shipping time: 7-10 days

    Product no.: ISO-115186
    EAN: 9009377097317
    In stock: 50

    Due to the wide range of product combination options, it is not always possible to display all items, including components and accessories, online.

    Please call us here, our trained sales team will be happy to advise and support you at any time in selecting the right items.

    We use Trusted Shops as an independent service provider for obtaining reviews. Trusted Shops has taken measures to ensure that the reviews are genuine.
    More information
    Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.
    To business registration

    ISO-115186 Corner connector for MiniAMP Flexband CRI919/940 1.5W

    The ISO-115186 corner connector is a practical accessory for MiniAMP Flexband CRI919/940 LED light strips. With a power of 1.5W and an operating voltage of 12V, this corner connector offers excellent light output of 150lm with a beam angle of 120°. The color rendering index is over 90, ensuring very good color reproduction.

    Dimmable corner connector with PWM pulse width modulation

    This corner connector is dimmable and supports PWM pulse width modulation to adjust the brightness of the light as needed. With dimensions of 3.2 x 3.2 x 0.2 cm and a cable diameter of 0.5 mm, this corner connector is compact and easy to install. Its dimmability allows for individual control of the light ambiance in the room.

    Versatile applications and high-quality construction

    The ISO-115186 corner connector is ideal for indoor use and can be used for various lighting projects. With a color temperature of 1900-4000K (Tunable White) and a color rendering grade of 1A, this corner connector offers a versatile lighting solution. The high-quality construction of plastic and copper ensures a long lifespan and reliable performance.

    Energy-efficient lighting solution with IP20 protection rating

    With an energy efficiency class of F and an energy consumption of 15kWh/1,000 h, the ISO-115186 corner connector is an environmentally friendly and cost-effective lighting solution. The IP20 protection rating provides sufficient protection against dust and contact. With an average lamp lifespan of 20,000 hours, this corner connector offers a long-lasting lighting solution.

    ISOLED corner connector: Reliable brand for high-quality LED products

    The ISO-115186 corner connector is from the renowned brand ISOLED, known for its high-quality LED products. With a color rendering of 90-100Ra and a neutral white light color, this corner connector offers a premium lighting solution. Ideal for recessed or surface mounting, this corner connector is a reliable and durable option for your lighting needs.

    Article number:
    ISO-115186
    Purchasing quantity:
    1 piece
    Brand:
    ISOLED
    Manufacturer:
    ISOLED
    Energy efficiency category:
    F
    EPREL No:
    821907
    Product type:
    corner connector
    Energy consumption:
    15 kWh/1.000 h
    Operating voltage:
    12 V=
    Dimmable:
    yes
    Dimmability:
    PWM dimming
    Power consumption:
    15 W
    Emitting angle:
    120 °
    LED can be replaced :
    no
    Bulb type:
    LED
    Light colour:
    ultra warm white
    warm white / neutral white (in steps)
    neutral white
    Light emission:
    direct
    Light yield:
    150 lm/m lm/W
    Colour temperature:
    1900-4000 K
    Average life span of a bulb in hours:
    20000 h
    Colour rendering index:
    90-100 Ra
    1A
    Contact gap:
    0,7 mm
    Colour:
    white
    Material:
    copper
    plastic
    Dimension:
    strip-W: 1 cm
    L∕ W∕ H: 3,2∕ 3,2∕ 0,2 cm
    Wire/connection lead diameter:
    0,5 ² mm
    Mounting:
    system based mounting
    surfaced mounting
    recessed mounting
    IP-protection class:
    IP20
    Application area:
    only suitable for indoor use
    Additional information:
    Very good colour rendering.
    Transformer power: 21 VA
    Accessories:
    driver excl
    LED Strip excl
    dimmer excl
    ambient temperature:
    0 ... +40 °C
